A Series - Hydraulic Cooler, Oil Cooler & Fuel Cooler

The A Series is a legacy product developed to interchange with ITT/Standard X-Change. Its non-ferrous design (brass shell) is ideal for water to water, including sea water cooling applications. This unit is not recommended for new applications.

Features

• ITT interchange
• B or C series is recommended for new applications
• Competitively priced
• NPT, SAE O-Ring, SAE flange, or BSPP shell side connections available
• End bonnets removable for servicing
• Mounting feet included (may be rotated in 90° increments)

Ratings

• Maximum Operating Pressure - Shell Side 300 PSI
• Maximum Operating Pressure - Tube Side 150 PSI
• Maximum Operating Temperature 300°F

Materials

• Tubes - Copper
• Hubs & Tubesheets - Steel or brass
• Shell - Steel or brass
• Baff les - Brass
• End Bonnets - Cast iron
• Mounting Brackets - Steel
• Gaskets - Nitrile rubber/cellulose fiber
• Nameplate - Aluminum foil
