AOL Series - Hydraulic Cooler, Oil Cooler & Fuel Cooler

The versatile and high performing AOL Series is applicable to both hydraulic and compressor oil cooling. The design features proven brazed aluminum P-BAR™ plate and bar core technology engineered with an aggressive turbulator that produces ultra high heat transfer. Vertical air flow and detachable legs offer endless mounting possibilities. This series is a light weight compact solution for extreme heat loads.

Features

• Large oil flow
• High performance
• Industrial duty
• Brazed aluminum bar and plate core
• All aluminum core assembly
• Eliminates high water and sewer costs
• Eliminates corrosion problems associated with water cooled units
• Vertical air flow works well for heat recovery
• P-BAR plate and bar core technology
• High performance air side fin design
• Detachable legs (shipped loose)
• CRN available

Ratings

• Maximum Operating Pressure 250 PSI
• Maximum Operating Temperature 300°F
• *CRN Rating 235 PSI at 250°F

Materials

• Legs Steel with baked enamel finish
• Shroud Steel
• Standard Core Brazed Aluminum Bar and Plate
• Tanks – 5052 Aluminum
• Nose Bar & Little Bar – 3003-H Aluminum
• Air Fin, Plate, Turbulator & End Plate – 3003-O Aluminum
• Fan Aluminum Hub, Plastic Blades
• Motor TEFC

Fluid Compatibility

• Petroleum/mineral oils
• Oil/water emulsion
• Water/ethylene glycol
