BPSW Series - Hydraulic Cooler, Oil Cooler & Fuel Cooler
Product Details
Brand:
TTP
The BPSW Series is rugged, compact and cost-effective, and is reliable over long periods of time with minimal maintenance. Design features of this highly-efficient series include 316 stainless steel construction and standard SAE connections. High plate channel turbulence effectively performs even in close approach temperatures. The compact size is an optimal heat transfer solution for industrial applications where space is limited. A wide offering of full featured standard models is available with short lead times and fast delivery.
Features
- Short lead time
- Stacked plate
- Stainless steel
- Copper brazed (nickel option)
- Oil to water applications
- High performance
- Compact design
- SAE connections
- Corrosion resistant Type 316 stainless steel plates
- Mounting studs standard (except 8x3 plates)
- SAE oil connections, NPT water connections
Ratings
- Maximum Working Pressure 450 PSI (31 BAR)
- Minimum Working Temperature -320ºF (-19°C)
- Maximum Working Temperature 437ºF (225°C)
Materials
- Plate Material -Fluid Contact - 316 stainless steel
- Braze Material - Copper (Nickel option)
- Connectors - 316 stainless steel
- Stud Bolts - 304 stainless steel
- Foot Mounting Bracket - Carbon steel
