BPW Series Heat Exchanger

Like the BPSW Series, the BPW Series is rugged, compact, and cost-effective, and is reliable over long periods of time with minimal maintenance. High plate channel turbulence effectively performs even in close approach temperatures. The BPW Series heat exchangers are made to order for your specific application with highly customizable sizes, ports and material options.

Features

• Customized sizes and options
• Stacked plate
• Stainless steel
• Copper brazed (nickel option)
• High performance
• Compact design
• Corrosion resistant Type 316 stainless steel plates
• Mounting studs standard (except 8x3 plates)

Ratings

• Maximum Working Pressure 450 PSI (31 BAR)
• Minimum Working Temperature -320ºF (-19°C)
• Maximum Working Temperature 437ºF (225°C)

Materials

• Plate Material Fluid Contact - 316 stainless steel
• Braze Material - Copper (Nickel option)
• Connectors - 316 stainless steel
• Stud Bolts - 304 stainless steel
• Foot Mounting Bracket - Carbon steel
