EC Series - Hydraulic Cooler, Oil Cooler & Fuel Cooler
Product Details
Brand:
TTP
The EC Series is a robust version of the EK series with the same efficiency, handling flows up to 250 GPM. The aluminum finned tube bundle design provides an increased surface area that allows for optimal heat rejection with low water usage. An optional Surge-Cushion® bypass is available for cold start up protection or flow surges. With multiple material options to choose from, this series can used in a wide variety of applications.
Features
- Rugged steel shell construction
- 3/8" tube size
- Larger shell diameter than EK, 8.50" maximum diameter
- High flow capacity & performance
- High efficiency finned bundle design
- End bonnets removable for easy tube cleaning
- Mounting brackets included – may be rotated for simple installation
- NPT, SAE, BSPP, BSPT or flange connections
Ratings
- Maximum Operating Pressure - Shell Side 300 PSI
- Maximum Operating Pressure - Tube Side 150 PSI
- Maximum Operating Temperature 300°F
Materials
- Shell - Steel
- Tubesheets - Steel
- Tubes - Copper
- Baff les - Steel
- Mounting Brackets - Steel
- Gaskets - Nitrile rubber/cellulose fiber
- Fins - Aluminum
- End Caps - Grey iron
- Nameplate - Aluminum foil
