MF Series - Hydraulic Cooler, Oil Cooler & Fuel Cooler

The Mobile MF Series offers the same features as the M Series with the addition of a low amp draw DC motor or long life hydraulic motor. The robust and rugged design includes aluminum fins, steel manifold and copper tubes. Other features include an optional built-in internal pressure bypass for cold start-up protection and the use of high-low turbulators for optimal heat rejection at lower flow rates. This series is ideal for higher pressure applications. Common applications include oil, fuel and transmission cooling.

Features

• Similar to M Series with DC fan or hydraulic motor
• 3/8" tube size
• Aluminum fins
• Low amp draw 12 or 24 volt DC motor
• Heavy duty construction
• Long life hydraulic motors
• Heat removal to 50,000 BTU/HR
• Oil flows to 150 GPM
• Mounting brackets included
• SAE, NPT or 37° flare oil connections
• Rugged steel manifolds

Ratings

• Maximum Operating Pressure 300 PSI
• Maximum Operating Temperature 350°F
• Motor Displacement .22in3/Rev. (Hydraulic)
• Maximum Pressure 2000 PSI (Hydraulic)
• Allowable Backpressure 1000 PSI (Hydraulic)

Materials

• Tubes - Copper
• Fins - Aluminum
• Turbulators - Steel
• Manifolds - Steel
• Fan Assembly - High Impact Plastic
