PF Series - Hydraulic Cooler, Oil Cooler & Fuel Cooler

The PF Series is a high-performing gasketed plate style heat exchanger. Able to handle large volumetric flows with low temperature drops, the design features large heat exchanging surfaces in a very compact, space-saving frame. The units can be readily expanded or reduced to accommodate changes in performance. This cost effective series is ideal for oil-to-water applications. Titanium plates are available for salt water service.

Features

• Gasketed plate style heat exchanger
• Oil to water applications
• High performance
• Can be disassembled for internal cleaning
• Plates can be added /removed to accommodate change in performance
• Medium to very high flows
• PED / ASME / CRN codings available

Ratings

• Design Pressure 150 PSI (10.5 BAR)
• Design Temperature 230°F (110°C)
• Minimum Working Temperature 32°F (0°C)

Materials

• Internal
• Plates - Stainless steel
• Gaskets - NBR-clip
• External Frame
• Connections - Carbon steel, stainless steel
• Frame Plate - Carbon steel
• Pressure Plate - Carbon steel
• Tie Rods - Zinc plated steel
• Carry Bar - Zinc coated steel, stainless steel
• Guide Bar - Zinc coated steel, stainless steel
• Column (if applicable) - Carbon steel, aluminum
• Mounting Feet - Carbon steel
• Fasteners - Zinc plated steel
• Other materials are available
