UC/UCV Series - Hydraulic Cooler, Oil Cooler & Fuel Cooler

Product Details

Brand: TTP

The UC/UCV Series features all-steel construction with a U-tube design that reduces stresses caused by thermal expansion. The UCV features rotated shell ports for removal of condensate. The tube bundle, removable for servicing, is standard on all models. This series is ideal for steam and large temperature differential applications.

Features

Steam & large temperature differentials
“U” tube
Removable tube bundle for servicing
3/8" Tubes
Built-in expansion chamber
Threaded or flanged connections
Mounting brackets included
Steel shell assembly
Reduces thermal expansion stresses

Ratings

UC Series:

Maximum Operating Pressure - Shell Side 250 PSI
Maximum Operating Pressure - Tube Side 150 PSI
Maximum Operating Temperature 400°F

UCV Series:

Maximum Operating Pressure - Shell Side UCV-600, 800 and 1000 250 PSI
Maximum Operating Pressure - Shell Side UCV-1200 and 1700 150 PSI
Maximum Operating Pressure - Tube Side 150 PSI
Maximum Operating Temperature 400°F

Materials

UC/UCV Series:

Tubes - Copper
Tube Sheets - Steel
Shell - Steel/316L stainless steel (UCV)
Shell Connections - Steel
Baff les - Stainless steel
End Bonnets - Cast iron
Mounting Brackets - Steel
Gaskets - Non-asbestos fiber/nitrile rubber
Nameplate - Aluminum foil
